Create a Code Co-occurrence Matrix and Network Plot

Builds a co-occurrence matrix showing how often qualitative codes appear together within the same unit (e.g., transcript, document, or media title). The function expects a coded dataset (excerpts) and returns both a formatted matrix and (optionally) a network visualization. The returned matrix can be displayed as raw counts or column-wise proportions, whereas the network plot always reflects the underlying raw counts.

Usage

cooccur(
  excerpts = NULL,
  min_bold = 10,
  scale = c("count", "prop"),
  output = c("kable", "tibble", "data.frame"),
  plot = TRUE,
  edge_min = 10,
  layout = "circle",
  edge_color_low = "lightgray",
  edge_color_high = "purple",
  node_color = "lightblue",
  use_labels = FALSE,
  codebook = NULL
)

Arguments

excerpts

Data frame containing coded excerpts, with a column named media_title and code columns prefixed with "c_".

min_bold

Minimum value for bold highlighting in HTML table output (if output = "kable"). Default is 10.

scale

Whether to display raw counts ("count") or column-wise conditional proportions ("prop") in the returned matrix. The network plot always uses raw counts. Default is "count".

output

The format of the co-occurrence matrix output. One of "kable", "tibble", or "data.frame". Default is "kable".

plot

Logical; whether to produce a network visualization. Default is TRUE.

edge_min

Minimum edge weight (in counts) for displaying connections in the plot. Default is 10.

layout

Graph layout for network visualization (passed to ggraph::ggraph). Common options include "circle", "fr", or "kk". Default is "circle".

edge_color_low, edge_color_high

Color gradient for edge weights in the plot. Default is "lightgray" to "purple".

node_color

Color for node points in the network plot. Default is "lightblue".

use_labels

Logical; if TRUE, replaces code variable names with descriptive labels from a provided codebook. Default is FALSE.

codebook

Optional data frame with columns:

variable: the code variable name (e.g., "c_family")
label: the descriptive name for the code (e.g., "Family Connectedness"). Required when use_labels = TRUE.

Value

A named list with two elements:

matrix: A tibble, data frame, or formatted HTML table of the co-occurrence matrix.
plot: A ggplot object visualizing the co-occurrence network (if plot = TRUE).

Details

The function identifies columns beginning with "c_" as code variables. It computes co-occurrences by summing pairwise intersections of codes across all unique media_title units. The diagonal represents the marginal frequencies (the number of transcripts where each code appears).

The resulting matrix can be output as a tibble, a simple data frame, or a formatted HTML table via knitr::kable. If plot = TRUE, the function also returns a network visualization of code co-occurrences using ggraph and igraph. Edges are filtered via the edge_min threshold, and nodes without any remaining connections are removed from the plot.

Examples

# Example 1: Basic co-occurrence matrix from excerpts
df <- data.frame(
  media_title = c("Doc1", "Doc2", "Doc3"),
  c_hope = c(1, 0, 1),
  c_family = c(1, 1, 0),
  c_school = c(0, 1, 1)
)

result <- cooccur(
  excerpts = df,
  scale = "count",
  output = "tibble",
  plot = TRUE
)

result$matrix  # Co-occurrence matrix
#> # A tibble: 3 × 4
#>   code     c_hope c_family c_school
#>   <chr>     <dbl>    <dbl>    <dbl>
#> 1 c_hope        2        1        1
#> 2 c_family      1        2        1
#> 3 c_school      1        1        2
result$plot    # Network plot


# Example 2: Use descriptive labels from a codebook and proportions in the table
codebook <- data.frame(
  variable = c("c_hope", "c_family", "c_school"),
  label = c("Hope & Optimism", "Family Connectedness", "School Belonging")
)

labeled_result <- cooccur(
  excerpts = df,
  use_labels = TRUE,
  codebook = codebook,
  scale = "prop",
  output = "kable",
  plot = TRUE
)

labeled_result$matrix
#> <table class="table table-striped table-hover table-condensed" style="width: auto !important; margin-left: auto; margin-right: auto;">
#> <caption>Code Co-occurrence Matrix (Within Transcript) Proportions</caption>
#>  <thead>
#>   <tr>
#>    <th style="text-align:left;">   </th>
#>    <th style="text-align:center;"> Hope &amp; Optimism </th>
#>    <th style="text-align:center;"> Family Connectedness </th>
#>    <th style="text-align:center;"> School Belonging </th>
#>   </tr>
#>  </thead>
#> <tbody>
#>   <tr>
#>    <td style="text-align:left;"> Hope &amp; Optimism </td>
#>    <td style="text-align:center;"> 1.000 </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>   </tr>
#>   <tr>
#>    <td style="text-align:left;"> Family Connectedness </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>    <td style="text-align:center;"> 1.000 </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>   </tr>
#>   <tr>
#>    <td style="text-align:left;"> School Belonging </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>    <td style="text-align:center;"> 0.500 </td>
#>    <td style="text-align:center;"> 1.000 </td>
#>   </tr>
#> </tbody>
#> </table>
labeled_result$plot
